Overview
The original NAD 3020 introduced a generation of music lovers to true high-fidelity sound. In the 1970’s, over a million people rediscovered their music when they placed a NAD 3020 between their turntable and loudspeakers. This little gem outshined amplifiers costing 10 times more with its big, warm, detailed sound. Today, the source is more likely to be a computer or smartphone than a turntable, but the ability to choose speakers that perfectly suit one’s taste is still a compelling argument for upgrading to an NAD amplifier. The D 3020 starts with the original NAD 3020 concept and brings it straight into the 21st century using the latest high-speed digital technology. Now with V2, we have refined the looks and added a Phono input for vinyl playback.
Specifications
| Rated Power at 8 ohms | 2 x 30 Watts |
| IHF Dynamic Power |
2 x 60 Watts at 8 Ohms 2 x 100 Watts at 4 Ohms 2 x 150 Watts at 2 Ohms |
| Signal/Noise Ratio (A-weighted, ref. 1 Watt) | ≥90dB |
| Channel Separation |
≥75dB at 1kHz ≥65dB at 10kHz |
|
Channel Balance |
0 ±0.3dB |
| Frequency Response (20Hz – 20kHz) | 0dB to -0.3dB |
| Total Harmonic Distortion | ≤0.005% |
| Maximum input level | 5V |
| IMD (SMPTE) | 0.02% |
| IMD (CCIF) | 0.003% |
| Phono Signal-to-Noise Ratio |
>82 dB (200 ohms source, A-weighted, ref. 500 mV out) 76 dB (MM cartridge source, IHF; A-weighted, ref. 500 mV out) |
| Phono Input sensitivity | 1.15 mV (ref. 500 mV out, Volume maximum) |
| Phono Maximum input signal at 1kHz | >90 mVrms (ref. 0.1 % THD) |
| Phono Frequency response | ±0.3 dB (20 Hz – 20 kHz) |
| Standby Power | ≤0.5 Watts |
| Supports bit rate/sample rate | up to 24/192 (via Digital Audio input) |
| Unit Dimensions (W x H x D) Gross |
58 x 186 x 219mm 2 5/16 x 7 3/8 x 8 5/8” |
| Net Weight | 1.38kg (3.05lb) |
| Shipping Weight | 2.1kg (4.6lb) |
